Product Description:
Hom: Sab nraum zoov FTP Cat5e Cable Aluminium Foil Screened Network Cable
Daim ntawv thov: Sab nraum zoov LAN thaiv
Qauv rau sab nraum zoov FTP Cat5e:
Tus coj | 24 AWG tooj liab hlau |
Rwb thaiv tsev | HDPE los yog foamed PE, dawb insulated hlau nrog cov xim cim |
Pair xim | Dawb-xiav/xiav, dawb-txiv kab ntxwv, dawb-ntsuab/ntsuab, dawb-xim av/xim av |
Hauv av electrode | Tinned tooj liab hlau |
thaiv | Aluminium Plastic Composite Daim kab xev |
Jacket | PVC {{0}} dub LLDPE, nominal txoj kab uas hla 6.1+/- 0.5 mm |
Pab txhawb | Poly ribbon, tsis muaj hlua khi, lossis raws li cov neeg siv khoom xaiv |
luam ntawv | Raws li cov neeg siv khoom xav tau |
Kev xeem tus qauv ntawm Sab Nraud FTP Cat5e:
YD/T1019-2013,ISO/IEC11801,TIA/EIA-568C.2,IEC/61156-5
Cov ntawv thov tseem ceeb:
Ethernet, 10Base-T, 1000Base-T4, 100Base-TX, ATM, multimedia, kab hluav taws xob
Mechanical zog:
Max rub zog | 50N |
Min. nkhaus radius | 60 hli |
Nominal hnyav | 50Kg/Km |
Ua haujlwm kub | -15~+70℃ |
Nruab kub | +5~+40℃ |
combustion khoom | IEC332.1,VW1,IEC332.3 los yog raws li ib hom sheathing |
Khoom ntev | Standard ntev 305m |
Hluav taws xob khoom rau sab nraum zoov FTP Cat5e:
Ntau zaus (Mhz) | RL (dB) | ATT (Db / 100m) | Tom ntej no (dB) | PSNEXT (dB) | ELFEXT (dB) | Khoom Impedance (ohm) |
0.772 | 16.4 | 1.85 | 67 | 64 | 67.8 | 100±15 |
1 | 17 | 2.04 | 65.3 | 62.3 | 63.8 | |
4 | 20 | 4.1 | 56.3 | 53.3 | 51.7 | |
8 | 21 | 5.8 | 51.8 | 48.8 | 45.7 | |
10 | 22 | 6.5 | 50.3 | 47.3 | 43.8 | |
16 | 20 | 8.2 | 47.3 | 44.3 | 39.7 | |
20 | 20 | 9.3 | 45.8 | 42.8 | 37.7 | |
25 | 22.5 | 10.4 | 44.3 | 41.3 | 35.8 | |
31.25 | 18 | 11.7 | 42.9 | 39.9 | 33.9 | |
62.5 | 16 | 17 | 38.4 | 35.4 | 27.8 | |
100 | 15 | 22 | 35.3 | 32.3 | 23.8 |
