Nyob rau hauv qhov chaw kub siab -, cov xov hlau zoo li cov hlab ntsha ntawm koj cov khoom siv.
Xaiv cov cable tsis raug tuaj yeem ua rau muaj teeb meem loj.PTFE siab-kub xaim yog tsim los rau huab cua kub, tab sis tsis yog txhua lub cables tau sib npaug. Koj yuav tsum xaiv kom zoo.
Yog vim li cas Ordinary Wires Fail nyob rau hauv siab kub
Thaum kub siab tshaj 70 degree, PVC los yog roj hmab xov hlau yuav tsis zoo:
Lub tsho sab nrauv tawg - Tsis muaj kev tiv thaiv sab laug.
Rwb thaiv tsev tsis ua hauj lwm - Rwb thaiv tsev tsis kam poob, ua rau hluav taws xob faults.
Tus neeg xyuas pib oxidation - Tsis kam nce, cua sov tsim, thiab lub voj voog loj zuj zus.
Cov pa phem tso tawm - PVC tuaj yeem tso cov pa phem thaum kub dhau.
Qhov no yog vim li cas siab -kub hlau yog qhov tseem ceeb hauv qhov chaw kub.
Dab tsi ua kom zoo PTFE High Temperature Hlau?
Lub siab - zoo PTFE insulated hlau tsis yog hais txog qhov ntsuas kub xwb. Nrhiav cov yam ntxwv tseem ceeb no:
- Kev ua haujlwm ruaj khov nyob rau hauv cov cua kub tsis tu ncua
- PTFE hlau zoo tuaj yeem ua haujlwm siab tshaj 200℃rau lub sijhawm ntev yam tsis muaj kev puas tsuaj.
- Zoo heev rwb thaiv tsev aging kuj
- PTFE rwb thaiv tsev tiv thaiv kev laus, nyob twj ywm saj zawg zog, thiab ua kom rwb thaiv tsev muaj zog nyob rau lub sijhawm.
- Tsis muaj tshuaj lom emissions
- PTFE tsis tso cov pa phem hauv qab cua sov, tsis zoo li PVC cov ntaub ntawv.
- Cov ntaub ntawv pov thawj xeem
- Xaiv cov kab hluav taws xob los ntawm cov tuam txhab ntseeg siab uas muaj cov ntaub ntawv xeem thiab ntawv pov thawj zoo li UL, TUV, thiab RoHS.
Dab tsi yog Sab hauv Kev Ntseeg Siab Siab Cable?
- Sab saum toj - cua sov zoo- resistant hlau muaj cov nram qab no kev tsim kho:
- Advanced rwb thaiv tsev ntaub ntawv: PTFE, FEP, PFA, los yog ETFE rau -200℃rau +260℃.
- Tinned tooj liab conductor: Tiv thaiv oxidation thiab ua kom ruaj khov conductivity.
- Thickened los yog kev cai tsho: Ntxiv durability thiab kub tsis kam.
- Cov ntawv pov thawj thoob ntiaj teb: Nrhiav UL, TUV, RoHS kom paub meej cov khoom lag luam.
Qhov twg High -Tsub Kab Xav Tau?
Qee qhov chaw xav tau kev lag luam siab -kub cables rau kev ua haujlwm nyab xeeb:
- Nyob ib ncig ntawm industrial furnaces
- Sab hauv motors thiab cav
- Automotive cav compartments
- LED tsav tsheb thiab thaj chaw cua sov
- Vuam tshuab thiab cua sov
- Aerospace thiab cov khoom siv tub rog
Tsuas yog PTFE siab -kub xaim lossis lwm yam cua sov- hom kab hluav taws xob tiv taus tuaj yeem muaj sia nyob cov xwm txheej no.
Summary : Xaiv Txoj Cai High Temp Cable
Thaum xaiv PTFE high temp hlau:
- Tshawb xyuas ntev -lub sij hawm kub stability, tsis yog qhov kub siab tshaj plaws xwb.
- Nug rau cov ntaub ntawv ntsuas kev ntsuas hluav taws xob thiab cov ntawv pov thawj kev nyab xeeb.
- Tsis txhob cuam tshuam rau qhov zoo kom txuag tau nqi - nws tuaj yeem ua rau muaj kev phom sij.
PTFE- insulated cable yog ib qho tseem ceeb ntawm kev nyab xeeb nyob rau hauv siab -kub tshuab. Xaiv kom zoo los xyuas kom ruaj khov thiab tiv thaiv koj cov khoom siv.
Xav tau kev cai siab -kub hlau? Peb muab OEM / ODM PTFE cable daws teeb meem nrog cov qauv xa khoom sai thiab ntawv pov thawj thoob ntiaj teb. Tiv tauj peb rau kev txhawb nqa thiab kev pom zoo.
| Tus coj | Rwb thaiv tsev | Cov khoom hluav taws xob | Ntim | |||
| Thaj tsam (mm²) | Conductor Tsim | Txoj kab uas hla (mm) | Rwb thaiv tsev Thickness (mm) | Sab nraud Dia (mm) | Max. Conductor Resistance DC 20℃Ω / km | M/coil |
| 0.014 | 7X0.05 | 0.15 | 0.15 | 0.45 | 1343.00 | 500 |
| 0.035 | 7X0.08 | 0.24 | 0.15 | 0.54 | 525.00 | 500 |
| 0.05 | 7X0.10 | 0.30 | 0.15 | 0.60 | 376.20 | 500 |
| 1X0.26 | 0.26 | 0.17 | 0.60 | 376.20 | 500 | |
| 0.07 | 1X0.30 | 0.30 | 0.20 | 0.70 | 245.00 | 500 |
| 0.08 | 7X0.12 | 0.36 | 0.20 | 0.76 | 227.00 | 500 |
| 0.12 | 7X0.15 | 0.45 | 0.20 | 0.85 | 150.00 | 500 |
| 0.2 | 7X0.20 | 0.60 | 0.25 | 1.10 | 83.50 | 500 |
| 0.35 | 19X0.16 | 0.80 | 0.25 | 1.30 | 49.50 | 200 |
| 0.5 | 19X0.18 | 0.90 | 0.25 | 1.40 | 36.00 | 200 |
| 0.75 | 19X0.23 | 1.15 | 0.28 | 1.70 | 22.70 | 200 |
| 1.0 | 19X0.26 | 1.30 | 0.25 | 1.80 | 19.00 | 200 |
| 1.2 | 19X0.28 | 1.40 | 0.30 | 2.00 | 15.30 | 200 |
| 1.5 | 19X0.32 | 1.60 | 0.30 | 2.20 | 11.70 | 200 |
| 2.0 | 19X0.37 | 1.85 | 0.30 | 2.45 | 9.45 | 100 |
| 2.5 | 19X0.41 | 2.05 | 0.40 | 2.85 | 6.86 | 100 |
| 4.0 | 37X0.37 | 2.59 | 0.40 | 3.38 | 4.51 | 100 |
| 6.0 | 37X0.45 | 3.15 | 0.50 | 4.20 | 3.05 | 100 |
