1.cov khoom piav qhia
1) Kev piav qhia
Tsis muaj hluav taws xob: 600V
Qhov kub thiab txias: -60oC ~ +200oC
Conductor: Tinned Copper
Rwb thaiv tsev: Silicone
Xim: Dub, Xim av, Liab, Txiv kab ntxwv, Daj, Ntsuab, Xiav, Ntshav, Grey, Dawb, Pob tshab, Daj / Ntsuab
2) Cov yam ntxwv siab kub tsis kam, kub tsis kam tiv thaiv acid, tiv thaiv roj, antisepsis thiab ya raws
3) Daim ntawv thov tib yam nrog cov xov hlau ruaj khov rau cov khoom siv hauv tsev, teeb pom kev zoo, cov khoom siv hluav taws xob, qhov ntsuas kub, lub dav hlau, kev dav hlau, kev lag luam kev lag luam khoom, metallurgy thiab chemical engineering.the automobil thiab nkoj, hluav taws xob. instrumentation, lub teeb kev lag luam machinery thiab hluav taws xob fais fab installation thiab lwm yam.
2.cov ntaub ntawv khoom
| Tus coj | Rwb thaiv tsev | Max.cond tsis kam (Ω/km) |
Unit Length (m) (Ft) |
|||
| Loj (AWG) |
Kev tsim kho (No./mm) |
Txoj kab uas hla (mm) |
Nominal Thickness (mm) |
Txoj kab uas hla (mm) |
||
| 26 | 7/0.16 | 0.48 | 0.78 | 2.04 | 143 | 305/1000 |
| 24 | 7/0.20 | 0.61 | 2.17 | 89.3 | ||
| 22 | 7/0.254 | 0.77 | 2.33 | 56.4 | ||
| 20 | 7/0.31 | 0.94 | 2.50 | 35.2 | ||
| 18 | 7/0.39 | 1.19 | 2.75 | 22.2 | ||
| 16 | 7/0.49 | 1.49 | 3.05 | 14 | ||
| 24 | 11/0.16 | 0.61 | 0.78 | 2.21 | 89.3 | 305/1000 |
| 22 | 17/0.16 | 0.76 | 2.32 | 56.4 | ||
| 20 | 26/0.16 | 0.94 | 2.50 | 35.2 | ||
| 18 | 41/0.16 | 1.18 | 2.74 | 22.2 | ||
| 16 | 26/0.254 | 1.49 | 3.05 | 14 | ||
| 14 | 41/0.254 | 1.87 | 3.43 | 8.78 | ||
| 12 | 19/0.47 | 2.36 | 3.92 | 5.53 | ||
| 0.30mm² | 12/0.18 | 0.71 | 0.78 | 2.27 | 59.78 | 305/1000 |
| 0.50mm² | 20/0.18 | 0.92 | 2.48 | 40.1 | ||
| 0.75 hli | 30/0.18 | 1.13 | 2.69 | 26.7 | ||
| 1 00mm² | 40/0.18 | 1.31 | 2.87 | 20 | ||
| 1.25 mm² os | 50/0.18 | 1.46 | 3.02 | 14.35 | ||
| 2 00mm² | 41/0.254 | 1.87 | 3.43 | 8.78 | ||
| 2.50 mm² os | 50/0.254 | 2.08 | 3.64 | 7.16 | ||
3.product video
4. khoom duab
5.FAQ
Q1: Kuv puas tuaj yeem tau txais cov qauv dawb?
A1: Peb tuaj yeem muab cov khoom uas twb muaj lawm coj mus kuaj dawb hauv cov khoom thauj. Yog tias muaj qee qhov kev xav tau tshwj xeeb, thov hu rau peb kom paub meej ntxiv.
Q2: Koj txoj kev ntim khoom yog dab tsi? Kuv puas tuaj yeem muaj lub pob customized?
A2: Peb muaj cov txheej txheem export pob. Yog xav paub ntxiv txog lub pob customized, thov hu rau peb.
Q3: Koj puas yog lub Hoobkas lossis tuam txhab lag luam?
A3: Peb yog lub Hoobkas. Peb muab txhua yam OEM / ODM kev pabcuam rau cov neeg siv khoom thoob ntiaj teb.
