2 Pair 0.2mm RVSP 485 Shielded Cable
Txheej txheem cej luam ntawm twisted tswj cable:
2 Pair 0.2mm RVSP 485 Shielded Cable yog tsim los xa cov teeb liab ruaj khov nrog kev teeb tsa qis dua thiab kev saib xyuas.
Ua nrog tinned tooj liab conductors thiab PVC rwb thaiv tsev, nws ua kom durability thiab saj zawg zog rau ntau yam ntawm RS485 thiab tswj cov ntaub ntawv siv.
Qhov kev sib tw twisted shielded cable muaj kev tiv thaiv zoo EMI thiab RFI, muab kev sib txuas lus cov ntaub ntawv huv hauv ib puag ncig uas muaj kev ntseeg siab thiab kev ua tau zoo tshaj plaws.
Vim li cas thiaj xaiv Rs485 Tswj Cable:
- High - cov ntaub ntawv zoo txuas ntxiv lub neej kev pab cuam, txo qhov zaus hloov, thiab txuag kev saib xyuas thiab tag nrho cov nqi.
- Kev hloov pauv tau yooj yim, yooj yim-daim kab xev tsim txuag lub sijhawm installers ntawm txoj haujlwm cabling nyuaj, ua kom nrawm thiab ua haujlwm tau zoo.
- Aluminium ntawv ci thiab tinned tooj liab braid shield kom meej meej, cuam tshuam -dawb teeb liab kis tau tus mob nyob rau hauv industrial thiab tsheb thauj mus los systems.
Shielded tswj cables yog dav siv:
Zoo tagnrho rau cov tshuab cua sov, cua txias tswj, tswj kev nkag, thiab kev sib txuas lus hauv kev lag luam.
Kuj tseem siv rau hauv tsheb ciav hlau, subways, thiab dav hlau thaiv, qhov chaw ruaj khov RS485 cov ntaub ntawv teeb liab thiab kev co kuj tseem ceeb.
Certified Quality:
Ua raws li RoHS, CE, thiab UL1685 cov qauv, ua kom muaj kev nyab xeeb, kev ua raws li ib puag ncig, thiab nplaim taws tiv thaiv rau kev siv thoob ntiaj teb.
Tswj Cable Custom Options Muaj:
Peb kuj txhawb nqa ntau yam ntawm cov kev cai tshwj xeeb kom tau raws li qhov sib txawv ntawm kev teeb tsa thiab cov txheej txheem.
Cov kev xaiv muaj xws li:
2 × 0.2mm² (24AWG) - zoo tagnrho rau luv luv - nrug RS485 teeb liab kis tau tus mob
2 × 0.5mm² (20AWG) - haum rau kev tswj thiab kev sib txuas lus
2 × 0.75mm (18AWG) - tsim los rau siab dua tam sim no lossis ntev - siv nrug
4 × 0.2mm / 2 Pair 0.2mm² - rau ntau -channel RS485 thiab sensor txuas
4 × 0.5mm / 2 Pair 0.5mm² - rau kev lag luam automation thiab cov ntaub ntawv tswj tshuab
Kev cai tiv thaiv hom, cov ntaub ntawv tsho (PVC, PE, LSZH, PUR), thiab kev xaiv luam ntawv kuj muaj.
Tiv tauj peb rau koj cov kev cai RS485 shielded cable los yog twisted khub tswj hlau yuav tsum tau - peb tuaj yeem tsim cov cables raws li koj qhov project tshwj xeeb thiab kev xav tau kev ua haujlwm.
| Yam khoom | Specification |
|---|---|
| Yam khoom | 2 Pair 0.2mm RVSP 485 Shielded Cable |
| Cov khoom siv coj ua | Tinned tooj liab |
| Number of Cores | 4 (2 Pairs) |
| Cov khoom siv rwb thaiv tsev | PVC |
| Rwb thaiv tsev xim | Daj / Dawb, Txiv kab ntxwv, Xiav, Xiav / Dawb |
| Shielding Structure | Aluminium Ntawv Nyiaj + Tinned Copper Braid |
| Sheath Material | PVC (Dub) |
| Rwb thaiv tsev Outer Diameter | 1.69mm 3 |
| Sheath Outer Diameter | 8.05mm ib |
| Sheath Thickness | 1.3 / 1.42 / 1.17 mm |
| Cov ntawv pov thawj | RoHS, CE, UL1685 |
| Tej kev siv | Cua sov, Cua Txias, Access Control, Tsheb ciav hlau, Subway, Aircraft |
